High measurement accuracy, integrated 24-bit ADC, and stable measurement up to 0.01 level can be achieved
Highly integrated, single-chip solution
Supports low power consumption mode
Low impedance: ≤6R
Low pressure drop: ≤1.5V
High measurement accuracy, integrated 24-bit ADC, and stable measurement up to 0.01 level can be achieved
Highly integrated, single-chip solution
Supports low power consumption mode
Low impedance: ≤6R
Low pressure drop: ≤1.5V
Display range: -19999~39999
Conversion rate: 3 Times per second
Product pressure drop: ≤1.5V
Loop impedance: ≤5R
Operating current: <1mA
Measuring accuracy: 0.01% FS±1 digit
Display mode: LCD/LED, with 8 different physical units
Reference voltage: 1.2V，50ppm/℃
Alarm output: 2-channel isolated switch alarm output
Temperature detection: Internal temperature detection function. Temperature compensation can be performed on the measurement results
